Lead-Free / RoHS 3 Compliant / REACH Compliant

Description
2 x 4 foot ESD Mat 2mm/0.079″ thick, Light Blue, 2 buttons, wrist strap, ground cord. High Temperature Resistant, designed for use with soldering irons and hot air soldering/desoldering equipment.

Specifications
Size: 24 inches x 48 inches (2 x 4 feet) -0/+2%
Thickness: 0.079″ (2mm)
Color: Light Blue
ESD Mat Material: Synthetic Rubber (The top layer is static dissipative. The bottom black layer is conductive)
Temperature Resistance: -25C up to 450C (Contact with soldering materials for short durations up to 200-300C usually will not cause discoloration. Slight discoloration may occur if high heat is applied for long durations.)
Resistance (Surface to Ground): 1×10^6 to 1×10^9 ohms
Resistance (Surface to Surface): 1×10^6 to 1×10^9 ohms

Includes:
2′ x 3′ x 0.079″ ESD Mat, with 2 pre-installed grounding buttons
6 foot grounding strap – 1M ohm
3-6 foot stretch cord antistatic wrist strap – 1M ohm

Grounding:
Lay the ESD Mat in position on your work surface (Light Blue side up, black side down). Snap the black ground cord to a grounding button on the ESD Mat. Connect the other end of the ground cord to a common ground point, such as the center screw of a standard AC electrical outlet, using the ring terminal located on the end of the ground cord. Testing is recommended to make sure the screw is properly grounded.
